Thiết bị lưu trữ NAS Synology DS1522+

    • CPU AMD Ryzen
    • Ram: 8GB DDR4 ( tối đa 32GB )
    • Hỗ trợ gắn 5 ổ cứng, mở rộng lên đến 15 ổ, tối đa 240TB
    • Công nghệ Synology Hybrid RAID (SHR), Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
    • Có thể gắn thêm ổ NVMe làm bộ nhớ đệm
    • Hệ thống mã hóa AES-NI
    • Kích thước: 166 x 230 x 223 mm
    • Trọng lượng: 2.7 kg

    Liên hệ chúng tôi để được hỗ trợ tốt nhất

    phone
    zalo
    facebook
    map
    Category:
    CPU
    		 CPU Model AMD Ryzen R1600
    CPU Quantity 1
    CPU Core 2
    CPU Architecture 64-bit
    CPU Frequency 2.6 (base) / 3.1 (turbo) GHz
    Hardware Encryption Engine
    Memory
    		 System Memory 8 GB DDR4 ECC SODIMM
    Memory Module Pre-installed 8 GB (8 GB x 1)
    Total Memory Slots 2
    Maximum Memory Capacity 32 GB (16 GB x 2)
    Notes
    • Synology reserves the right to replace memory modules with the same or higher frequency based on supplier’s product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
    • Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
    • For more information about the recommended memory configurations, please check the Hardware Installation Guide of your Synology product.
    Storage
    		 Drive Bays 5
    Maximum Drive Bays with Expansion Unit 15 (DX517 x 2)
    M.2 Drive Slots 2 (NVMe)
    Compatible Drive Type* (See all supported drives)
    • 3.5″ SATA HDD
    • 2.5″ SATA SSD
    • M.2 2280 NVMe SSD
    Hot Swappable Drive*
    Notes
    • The hot swappable drive feature is not supported by M.2 SSD slots.
    • “Compatible drive type” indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
    External Ports
    		 RJ-45 1GbE LAN Port 4
    USB 3.2 Gen 1 Port* 2
    Expansion Port 2
    Expansion Port Type eSATA
    Notes
    • This device’s 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
    • The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
    PCIe
    		 PCIe Expansion 1 x Gen3 x2 network upgrade slot
    Appearance
    		 Size (Height x Width x Depth) 166 mm x 230 mm x 223 mm
    Weight 2.7 kg
    Others
    		 System Fan 92 mm x 92 mm x 2 pcs
    Fan Speed Mode
    • Full-Speed Mode
    • Cool Mode
    • Quiet Mode
    Brightness Adjustable Front LED Indicators
    Power Recovery
    Noise Level* 22.90 dB(A)
    Scheduled Power On / Off
    Wake on LAN / WAN
    Power Supply Unit / Adapter 120 watts
    AC Input Power Voltage 100V to 240V AC
    Power Frequency 50/60 Hz, Single Phase
    Power Consumption 52.06 watts (Access)
    16.71 watts (HDD Hibernation)
    British Thermal Unit 177.64 BTU/hr (Access)
    57.02 BTU/hr (HDD Hibernation)
    Notes
    • For more information on how power consumption is measured, refer to this article.
    • Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle state. Two GRAS 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
    Temperature
    		 Operating Temperature 0°C to 40°C (32°F to 104°F)
    Storage Temperature -20°C to 60°C (-5°F to 140°F)
    Relative Humidity 5% to 95% RH
    Certification
    • FCC
    • CE
    • BSMI
    • VCCI
    • RCM
    • UKCA
    • EAC
    • CCC
    • KC
    Warranty
    		 3-year hardware warranty, extendable to 5 years with Extended Warranty Plus
    Notes
    • The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
    • Extended Warranty Plus is only available in Europe and North America. Refer to the Extended Warranty Plus website for details on supported countries/regions. (Learn more)
    Environment
    		 RoHS Compliant
    Packaging Content
    • Main Unit X 1
    • Accessory Pack X 1
    • AC Power Adapter X 1
    • AC Power Cord X 1
    • RJ-45 LAN Cable X 2
    • Quick Installation Guide X 1
